MAGNIFICATION SCREEN
Magnify Screen Area
ARCADE BUTTONS
GREEN = Y
YELLOW = B
RED = A
BLUE = X
POWER ON BUTTON
Turn The Console On/Off
TRIGGER L1
L1 Button Trigger
e.g Main Weapon
TRIGGER LEDS
Red LED On When Trigger L1 Pressed
TRIGGER L2
L2 Button Trigger
e.g Secondary Weapon
GRIP
Handle / Grip
Vol+/- Buttons
Turn The Console Volume Up / Down
R1 Button
Arcade Button (R1 Shoulder)
R2 Button
Arcade Button (R2 Shoulder)
Y Button
GREEN (Y) Button
B Button
YELLOW (B) Button
A Button
RED (A) Button
X Button
BLUE (X) Button
Access Panel
Button Escartment Access Panel
Stand
Angle Adjustment Stand
